DCBORE for Windows

Bore hole logs acc. to DIN 4023 / EN ISO 14688 / SN 640 034 / 670 008 / OENORM B 4400-1 / BS 5930 Level and well finish incl. multi-level pipes.

Layer specifications

Layer specifications acc. to DIN 4022 p. 1 and EN ISO 22 475-1

• DIN 4023:2006 and EN ISO 22 475-1 available !
• Short and long designations
• Automatic conversion of short designations to long text
• Color and consistencies
• Soil group and soil class
• Water levels (stationary, rising)
• Samples (different types)
• Symbol editor for free definitions of: short and long texts, symbols and colors
• Extensive configuration of the graphic
• Free selection of any Windows fonts
• Customizable title block
• Any sheet formats up to A0
• Export of graphics in JPG format (i.e. for Word)
• Immediate graphical control
• Simple changes by double click
• Project-referred saving in data bases
• Swiss, Austrian and BS version (VSS/ÖNORM/BS) available
• English, German, French language
• symbols acc. to DIN, OENORM, SN and British Standard !

Contains as a Standard:

• Color output acc. to DIN 4023
• Layer specifications acc. to DIN 4022 p. 1 and  EN ISO 22 475-1
• Level and well finish acc. to DIN 4943:2013
• Display of geothermal borings

Further processing for Geological sections with position and height-based arrangement with the program DCSECTION

Supplements:

• DCBORE-Geotherm: heat extraction of geothermal borings acc. to VDI guideline 4640
• DCSTAN for Windows: SPTs (Standard Penetration Test) at the log or in a separate diagram
• DCBORE-Data logger for Windows: Measure values as lines or bars, linear or logarithmic
• DCBORE-SEP: Interface for the import and export of data in SEP format (NLfB)
• DCBORE-ASCII: ASCII interface for the import and export of bore hole logs
• DCBORE-Profiltec: Interface to Geologik ProfilTec-Feldbuch: Import of bore hole logs
