Mat3D is a general multi-pier mat foundation analysis/design tool for soil or pile supported foundations. It has the following features: Allows multiple system of units for input and output - English, Metric and SI Supports ACI 318 a...
MFoundation is a tool for code-based design and verification of bearing piles, tension piles and shallow foundations. For pile design it requires input data from Cone Penetration Tests (CPT). In addition to manual input, it can import data in GEF and...
2D & 3D finite element package for tunnel analysis. More than 20 years of continuous development and validation has resulted in CESAR-LCPC becoming the acknowledged reference tool in the field. Its intuitive and highly interactive graphical inte...
OptumG2 is a finite element program featuring many analysis types including elastoplastic deformation analysis, seepage, and staged construction analysis. It provides full integration of limit, elastoplastic and seepage analysis, providing an ideal p...
Foundation3D is a spread and combined footing analysis/design tool for soil or pile supported foundations for industrial equipment such as horizontal exchanger, horizontal vessel, vertical vessel or tower, pipe racks and other miscellaneous plant des...
StoneC is a software that performs design calculations of vibro replacement. Vibro replacement is an accepted method for subsoil improvement, that is achieved with the installation of large columns of coarse backfill material in the ground, using sp...
FOXTA is a program for the design of shallow foundations, deep foundations, pile groups, piled-raft foundations, rigid inclusions, etc. It is composed of 8 modules: shallow and deep foundations, oedometric settlement of a multi-layered soil, pile axi...
DynaN carries out the dynamic analysis of shallow and deep foundations based on the improved Novak's method where a non-reflective boundary is formed between the near field and the far field to account for the mass of soil in the boundary. The progra...
FB-Deep is a program that estimates the static axial capacity of drilled shafts and driven piles. The program also features connectivity to the FDOT Geotechnical Database, where soil data can be uploaded and downloaded. Drilled shaft methodology is b...
DIADIM is used for the design of flexible retaining structures such as concrete diaphragm walls, beam bulkheads, sheet piles and concrete piles using a finite element method to model the soil-structure interaction. The deformability of the ground is...
An application for the analysis of piles and pile groups according to various design methods. UniPile considers bearing capacity, pile group settlement, negative skin friction, and drag load. Aspects of drivability and residual stress are also inclu...
ALP99 carries out the analysis of an axially loaded pile modelled as an elastic pile supported by elasto-plastic springs.
Pile-MP calculates the bearing capacity of a single pile, or minipile, or a group of minipiles, carrying any loading combination (moment, normal force and shear). Structural calculation yields dimensions of longitudinal reinforcement and tie bars. Pr...
Section Analyzer for Piling Professionals Description: Piles Section is an engineering app which offers Cross Section Evaluation and Visualization of Cast-in-Place Bored Piles which are also referred as Drilled Shafts Features: Swiftly choos...
VERSAT-P3D is a finite element computer program for quasi-3D nonlinear dynamic analyses of single piles and pile groups in frequency and time domain (Wu and Finn, 1997, Canadian Geotechnical Journal 34: 34-52). The frequency-domain analysis is used t...
