Advanced and intuitive finite element modelling software for beam foundations. Package includes analysis of Analysis of beam foundations using discrete spring-bed model and elastic half-space model.
Supported on Windows & macOS and on the cloud using a browser
One click computation and analysis for all load cases and models.
- Analysis of the beam foundation using both/either models.
- Multiple load cases could be considered.
- Graphical representation of the Plan and Elevation View of the beam foundation.
- Graphical representation of loading diagrams for each load case.
- Data can be input in either SI units or ‘Commonly used American units’ (Kips for force and foot for length).
- Export results to Microsoft Word & Excel
- The loading may consist of several concentrated loads & moments
- Multiple uniformly distributed loads can be specified.
- Self-weight may be included if required.
- Different depths and breadths could be given for the beam. RCC inverted T beam sections and RSJ s could be considered by prescribing EI values directly.
- Vertical displacements, rotations, vertical spring & rotational spring could be prescribed if required.
- Supports Windows & macOS and on cloud using a browser
