Walls-Dimensioning

The dimensioning of retainment walls is a time consuming task. The program WALLS-Dimensioning performs this task with only a few mouse clicks and generates an inspection-oriented printout.

User interface

• Clear arranged, interactive user interface
• Detailed on-line assistance
• Fast and easily operated
• Expandable profile data base is provided
• Full integration into the program chain WALLS

Computation

• Dimensioning of all common types of pit lining walls
• Berlin wall with wood infill or shotcrete infill
• Sheet pile wall
• Diaphragm wall
• Bored pile wall:
•   with straight shotcrete infill checked for bending and/or arch effect
•   as arch with curved infill
•   with infill constructed form piles and taking automatically into account the effect of com-pressed arch

• „Mixed-In-Place“ wall
• Dimensioning of the anchors (temporary and/or permanent wire and single bar anchors)
• Dimensioning of waling
• Profile suggestion from a data base, which fulfills all stress checks
• In-situ concrete walls dimensioned according to max. forces and/or selected construction stages in order to graduate the reinforcement
• Dimensioning according to the standards DIN 1045, DIN 1045-1, EC2, SIA and OENORM

Results

• RTF Format (MS Office compatible)
• Direct print output containing mixed text and graphics
• Pictures drawn to scale, thus offering good control of the results
